Project Description

For Great Lakes or small fishing holes, only one name will do.

When you’re chasing horizons, you want an outboard that delivers optimum performance and peace of mind. Which is why you want the Honda BF135. These engines created the benchmark for a new generation of marine engine technology, and they’re the choice of center console, catamaran, pontoon, and bay boat owners across the country.

Honda BF135 features advanced Dual Overhead Cam, in-line four-cylinder architecture, a benefit from decades of Honda automotive and racing experience. Racing experience means more horsepower and instant throttle response. Honda’s exclusive Dual-Stage Induction delivers top performance at every rpm range. And Lean Burn Control automatically adjusts the air-fuel mix to maximize power and fuel efficiency.

All of which makes it clear: when it comes to boating, nothing beats the fuel efficiency and precision standards of Honda.

LEAN BURN CONTROL®

Inclusion of Lean Burn Control® offers significantly improved fuel consumption over Direct Injection two-stroke models and even further improved consumption over competing four-stroke models.
The mode in which lean burn control is used, is referred to as ECOmo (Economy Controlled Motor).

NMEA2000® COMPATIBLE

NMEA2000® compatibility allows the engine to communicate with onboard marine electronics to deliver a wide-range of information to head-unit displays. When networked with a NMEA2000®capable marine electronics unit, engine data such as speed, rpm, temperature, fuel usage and other data can be displayed on the unit’s screen.

  • Variable trolling speed. The system adjusts in 50rpm increments between 650-900rpm. (Trolling switch optional extra).
  • Three-Way Cooling. Three separate cooling circuits for more power with long-term durability.
  • ‘On Demand’ 40amp, belt-driven alternator reduces heat build-up and provides superior battery charging capability – 30amp at 1000rpm and 40amp at 2000rpm+!
  • 4-Front Corrosion Protection. A patented, ‘double-sealed’ multi-layered paint process. Sacrificial anodes and stainless steel technology, along with waterproof connectors, all enhance corrosion protection.

Engine

BF135
Type 4-Stroke DOHC 4 Cylinder/16 Valves
Displacement 2,354 cc (144 cubic inches)
Bore & Stroke 87 mm x 99 mm (3.4 x 3.9 inches)
Full Throttle RPM Range 5,000-6,000 RPM
Rated Power 135 HP @ 5,500 RPM
Cooling System Water Cooled
Fuel Delivery Programmed Fuel Injection
Ignition System MicroComputer Programmed
Starting System Electric
Exhaust Through Hub
Lubrication Wet Sump
Trim Range -4° to +16°
Tilt Range 72°

Drive

BF135
Gear Ratio 2.14:1
Gear Shift F-N-R
Alternator (Electric Start) 51 Amp
Battery Charging Power 30 Amp (1000 RPM), 40 Amp (2000+ RPM)
Propeller Optional
Power Tilt NA
Power Trim & Tilt Standard
Gas Assisted Tilt NA
Oil Pressure Alert Standard
Temperature Alert Standard
Rev-Limiter Standard
Speedometer Pickup Standard

Dimensions

BF135
Overall Width 580 mm/22.8 inches

Transom Height

BF135
L Type 508 mm/20 inches
X Type 635 mm/25 inches

Dry Weight

BF135
L-Type 217 kg/478 lbs.
X-Type 220 kg/485 lbs.
