Project Description

With a powerful 1.5L, Single Over Head Cam shaft (SOHC), 16-valve, inline four-cylinder engine, the BF100 is ready to set new levels of performance in the 100hp sector.

A perfect blend of Honda’s world renowned marine and automotive technologies, light weight and compact design assures these engines are a firm favourite with boating enthusiasts.

Provision of PGM-FI, Blast, and ECOmo, combine to ensure a perfect blend of power and fuel economy throughout the engine operating range. The 100hp also has VTEC™ functionality which assist performance by introducing two sets of cam shaft profiles for a wider operating range.

The BF100 is simplified easy connectivity with other popular NMEA2000® equipment, such as chart plotters or fish finders.

Trolling control between 650–1000rpm provides accurate slow speed control, ideal for fishing or marina maneuvering.

BEST IN CLASS

The BF80 and BF100’s 1.5L, SOHC, 16-valve, inline four-cylinder engine is inspired by the same remarkable engine that powers the iconic Honda motor vehicle, the ‘Jazz’.
With the exception of the cylinder sleeves, these engines feature an all-aluminium alloy block, resulting in a very lightweight and powerful package.

LEAN BURN CONTROL

Adjusts the air/fuel mix according to speed and load to maximise efficiency.
Inclusion of lean burn control offers significantly improved fuel consumption over direct injection two-stroke models as well as over competing four-stroke models.
The mode in which lean burn control is used is referred to as ECOmo (Economy Controlled Motor).

RACING TECHNOLOGY

VTEC™ ensures smooth, stable idling with an even further reduction in fuel consumption, while the increased valve lift at high revs broadens the torque curve and provides incredible top-end power.

Variable Valve Timing and Lift Electronic Control (VTEC™) delivers more power, torque and efficiency at every speed.

At 5200rpm, a high-lift cam engages to pack more air into the combustion chamber to produce more power.
VTEC™ works to produce a longer, flatter torque profile: the ultimate in fine-tuned performance. (VTEC™: BF100 only).

TROLLING CONTROL

Trolling Control allows slow speed control with adjustments in 50rpm increments between 650-1000rpm. Trolling Control is an optional feature
on the BF100. (Please speak with your authorised Honda Marine dealer.)

  • Powerful 1.5L, SOHC, 16-valve, inline
    four-cylinder engine.
  • Tiller steer option available.
  • 4-Front Corrosion Protection. A patented, ‘double-sealed’ multi-layered paint process. Sacrificial anodes and stainless steel technology, along with waterproof connectors, all enhance corrosion protection.
  • NMEA2000® compliant.

Engine

BF100
Type 4-Stroke SOHC 4 Cylinder/16 Valves
Displacement 1,496 cc (91.4 cubic inches)
Bore & Stroke 73 mm x 89.4 mm (3.0 x 3.5 inches)
Full Throttle RPM Range 5,500-6,300 RPM
Rated Power 100 HP @ 5,900 RPM
Cooling System Water Cooled
Fuel Unleaded Gas (93 Octane)
Fuel Delivery Programmed Fuel Injection
Ignition System MicroComputer Programmed
Starting System Electric
Exhaust Through Hub
Lubrication Wet Sump
Trim Range -4° to +16°
Tilt Range 68°

Drive

BF100
Gear Ratio 2.33:1
Gear Shift F-N-R
Alternator (Electric Start) 44 Amp
Battery Charging Power 35 Amp
Propeller Optional
Power Tilt NA
Power Trim & Tilt Standard
Gas Assisted Tilt NA
Oil Pressure Alert Standard
Temperature Alert Standard
Rev-Limiter Standard
Speedometer Pickup Standard

Dimensions

BF100
Overall Width 480 mm/18.9 inches

Transom Height

BF100
L Type 508 mm/20 inches
X Type 635 mm/25 inches

Dry Weight

BF100
L-Type 163 kg/359 lbs.
X-Type 166 kg/365 lbs.
